Jacks

Worm gear jacks from UNIMEK SpA are easy to use, reliable and require a minimum of maintenance. This makes them a very useful machine element in many different contexts.



They can be used to:
• lift
• drag
• balance
• position



Even with very high demands on personal safety, the jack is a useful alternative because the worm screw in our jacks is 100% self-locking. They can be used without external braking or locking devices. The lifting force of our jacks is a maximum of 1000 kN.

Self-locking worm gear and trapezoidal screws

Gearbox manufactured in aluminium, cast iron or steel depending on size


• Worm screw made of case-hardened steel 18NiCrMo5
• Worm wheel in bronze alloy
• Spindles of hardened carbon steel C40 with trapezoidal thread according to DIN 103



The pdf catalog is a shortened version. The complete catalog can be ordered from our sales staff



Jacks for ball screws

Can be adapted for most ball screws on the market and can be delivered with or without the ball screw.

Aleph jacks with housing in composite

This series of jacks has a housing and worm wheel made of a composite material.



This means, among other things, that it can work without lubrication – an advantage in many built-in cases. Currently, aleph is available in three sizes, all with trapezoidal screws.
