Bearing units

Slewing bearing is a wire bearing that is fitted with an inner and outer ring. The advantage of this system is i.a. that the outer and inner ring can be made of materials other than steel – eg aluminum for light weight.

LVA series

The LVA is a bearing made of steel, designed for medium-fast rotational speeds and precision.



LVA is a ready-to-install complete ball bearing with integrated wire ball bearing. With its 4-point technology, loads are absorbed from all sides, which makes the bearing resistant to both shocks and vibrations.



The bearing is sealed on both sides and pre-tensioned without play, which you can adjust yourself.



Material:

  • House rings: C45N
  • Wire rings: 54SiCr6
  • Rolls: 100Cr6
  • Baskets: PA12
  • Sealing: NBR



Temperature:

-20°C +80°C, exceptions up to +100°C



Peripheral speed:

Max 5 m/s, without seal max. 10 m/s



Lubricant:

Shell Gadus S3 V220C2

LVB series

The LVB is a ready-to-install aluminum bearing with integrated steel wire ball bearing, designed for medium-fast rotational speeds and precision.



With its 4-point technology, loads are absorbed from all sides, making the bearing resistant to boat impacts and vibrations. The bearing is sealed on both sides and pre-tensioned without play, which you can adjust yourself.



Material

  • Housing rings: AlZnMgCu05 Wire rings: 54SiCr6
  • Rollers: 100Cr6
  • Baskets: PA12
  • Seal: NBR



Temperature:

-20°C +80°C, exceptions up to +100°C



Peripheral speed:

Max 5 m/s, without seal max. 10 m/s



Lubricant:

Shell Gadus S3 V220C2



LVC series

The LVC has a double steel wire ball bearing design. Franke bearings of the LVC type are suitable for high peripheral speeds.



A big advantage is its high dynamics and low rotational resistance. LVC is a ready-to-install, maintenance-free complete ball bearing system with a long service life thanks to its low friction.

Material

  • Housing rings: C45N
  • Wire rings: 54SiCr6
  • Rollers: 100Cr6
  • Baskets: PA12



Temperature:

-20°C +80°C, exceptions up to +100°C



Peripheral speed:

Max 20 m/s



Lubricant:

Shell Gadus S3 V220C2

LVD series

VD is a bearing with steel external gears and rings, designed for medium-fast rotational speeds and precision. LVD is a ready-to-install complete ball bearing with integrated wire ball bearing.



With its 4-point technology, loads are absorbed from all sides, which makes the bearing resistant to both shocks and vibrations. The bearing is sealed on both sides and pre-tensioned without play, which you can adjust yourself.



Material

  • Housing rings: C45N/42CrMo4V
  • Wire rings: 54SiCr6
  • Rollers: 100Cr6
  • Baskets: PA12, Seal: NBR



Temperature:

-20°C +80°C, exceptions up to +100°C



Peripheral speed:

Max 5 m/s, without seal max. 10 m/s



Lubricant:

Shell Gadus S3 V220C2



LVE series

The LVE is a timing belt gear bearing with aluminum rings, designed for medium speed rotation speeds and precision. LVE is an installation-ready complete ball bearing with integrated wire ball bearing.



With its 4-point technology, loads are absorbed from all sides, which makes the bearing resistant to both shocks and vibrations. The bearing is sealed on both sides and pre-tensioned without play, which you can adjust yourself.



Material:

  • Housing rings: AlZnMgCu05
  • Wire rings: 54SiCr6
  • Rollers: 100Cr6
  • Baskets: PA12
  • Seal: NBR



Temperature:

-20°C +80°C, exceptions up to +100°C



Peripheral speed:

Max 5 m/s, without seal max. 10 m/s



Lubricant:

Shell Gadus S3 V220C2



LVG series

LVG is a two-row angular contact bearing made of aluminium, suitable for high loads. Advantages are its torsional rigidity, low rotational resistance and low weight.



LVG is a ready-to-install complete bearing with integrated wire ball bearing. Designed as a roller bearing, loads are absorbed from all sides, which makes the bearing resistant to both impacts and vibrations.



The bearing is sealed on both sides and pre-tensioned without backlash. LVG weighs 60% less compared to steel bearings thanks to its aluminum construction.

Material

  • Housing rings: ENAW7022
  • Wire rings: 67SiCr5
  • Rollers: 100Cr6
  • Baskets: POM
  • Seal: NBR



Temperature:

-20°C +80°C, exceptions up to +100°C



Peripheral speed:

Max 4 m/s



Lubricant:

Shell Gadus S3 V220C2
